Concrete Batching Plant JS 1000

The concrete batching plant js 1000 is actually a concrete plant with the js1000 twin shaft forced concrete mixer as the main engine, also known as the 1 cubic meter concrete batching plant, a 1 m3 concrete batching plant, and the models include hzs50 and hzs60, which can stir one side at a time. In fact, concrete batching plant js1000 can stir 0.8 cubic meters, and the theoretical output per hour is about 50-60 cubic meters.

The model and output of the concrete batching plant js 1000 are divided into hzs50 and hzs60 concrete batching plant. The following introduces the configuration parameters and output of the two types of concrete batching plants.

The standard configuration of the HZS50 concrete batching plant is a Js1000 forced concrete mixer with a leg height of 4.8 meters, with a walking platform guardrail and a material receiving nozzle part, and a PLD1600 three-storey gas-type concrete batching machine. Stone weighing ratio, weighing accuracy ± 2%, a complete set of water metering system and cement metering system, and the user is equipped with two 100T cement silos and a set of fully automatic centralized control system. The theoretical productivity of HZS50 concrete batching plant is 50 cubic meters per hour, the actual output is 35-40 cubic meters per hour according to the operation proficiency and equipment maintenance, and the daily output is about 350-400 cubic meters.

The standard configuration of a set of HZS60 concrete batching plant is as follows: one JS1000 forced concrete mixer, one PLD1600 four-storey concrete batching machine (straight belt type), one set of cement weighing, one set of fly ash weighing, one set of water weighing, a set of admixture weighing, a set of inclined belt feeding racks and waiting silos, 3 heels of 219-type 9-meter spirals, 3 100-ton cement silos, a set of air control system, and a set of automatic control system. The theoretical productivity of HZS60 concrete batching plant is 60 cubic meters per hour, the actual output is 45-59 cubic meters per hour according to the operation proficiency and equipment maintenance, and the daily output is about 450-590 cubic meters.

Haomei Machinery has been engaged in the production and manufacture of concrete mixers and mixing stations for 30 years. It has produced from JS500-JS2000 forced concrete mixers, from HZS25 concrete batching plant to HZS240 concrete batching plant. To purchase concrete batching plant js 1000 equipment, please go to regular concrete batching plant manufacturers like us, welcome to visit our factory!
